Designed for professional video decoding, the Kiloview D350 4K H.265/H.264 IP Video Decoder supports up to UHD 4K60 video input and output and can simultaneously decode up to 9 channels of 1080p60 or 16 channels of 1080p30 IP video. It features one 3G-SDI and two HDMI outputs, supports multiple audio formats, and offers multiple display options. The D350 has an integrated display for real-time monitoring and it supports NDI|HX2, NDI|HX3 (beta), full NDI, SRT, RTMP, RTMPS, HLS, TS over UDP, RTP, and RTSP for decoding from any streaming source.
Simultaneously Decodes up to 16 Channels
The D350 decoder supports simultaneous decoding of up to 16 streams, depending on the resolution:
4Kp60 NDI: 1 x channel
4Kp30: 2 x channels
1080p60: 9 x channels
1080p30: 16 x channels
Output Options
Two HDMI 2.0 ports and one 3G-SDI port supports three output options:
Independent outputs
A combination of multichannel video output
Simultaneous, single-stream replication
User-Defined Display Layouts
Customized multi-output displays include grids and PiP, PbP, and PoP
Adjustable frame rates, output resolutions, and de-interlacing
View up to 9 output streams and up to 16 previews
Dual USB Interfaces
USB-A and USB-C ports offer PTZ camera control using a USB keyboard, connection to an SSD for local storage, and intercom use via a USB headset
RMTP Server Support
The D350 can simplify your workflow by directly accessing a video encoder and outputting video streams through RTMP without any relay platform
Audio Decoding Options
Supported audio formats include AAC, AAC MPEG-4, MPEG-2, G.711, Opus, and LPCM
Real-time audio mix and audio gain to output alternatively through its HDMI ports, SDI port, and 3.5mm line out port
Audio switching off/on
Kiloview D350 Specs
Inputs / Outputs
Video Inputs
2x RJ45
Audio Inputs
No
Video Outputs
1x BNC (3G-SDI) 2x HDMI (2.0)
Audio Outputs
1x 1/8" / 3.5 mm TRS Stereo Analog
Other I/O
1x USB-A 1x USB-C
Expansion Slots
No
Latency
to 200 ms
Format Support
Input Video Format
RJ45 UHD 4K at 30 fps 1080p at 30/50/60 fps 1080i at 50/60 fps 720p
Output Video Format
SDI 1080p at 24/25/29.97/30/50/59.94/60 fps 1080i at 50/59.94 fps 720p at 50/59.94/60 fps 576i / 625 lines at 50 fps 480i / 525 lines at 60 fps HDMI UHD 4K at 25/30/50/60 fps 1080p at 24/25/30/50/60 fps 1080i at 50/60 fps 720p at 50/60 fps
