EX-FS-100 - VAVE USB3.0 Extender 100m

EX-FS-100 - VAVE USB3.0 Extender 100m
EX-FS-100 - VAVE USB3.0 Extender 100mEX-FS-100 - VAVE USB3.0 Extender 100m
รหัสสินค้า SKU-02370
หมวดหมู่ vave
ราคา 0.00 บาท
VAT7% สอบถามเพิ่ม
สถานะสินค้า Pre-Order
ลงสินค้า 17 ม.ค. 2568
อัพเดทล่าสุด 17 ม.ค. 2568
คงเหลือ ไม่จำกัด
จำนวน
ชิ้น
หยิบลงตะกร้า
หนังสือรับรองบริษัท
บุ๊คแบ๊งค์
คุ้มครองโดย LnwPay
Tags : HDBaseTExtender, 18GbpsTransmission, 4K120mRange, FullHD150mRange, 4KHDMIExtender, VideoTransmissionSolutions, AVOverLongDistances

รายละเอียดสินค้า

EX-FS-100 - VAVE USB3.0 Extender 100m The USB 3.0 Extender extends USB signals up to 100m (328ft) using a single CAT6a cable. The transmitter includes one USB 3.0 Type B input, one FSYSNC GPIO input, and one RS-232 pass-through. The receiver provides four USB 3.0 Type A outputs, one FSYSNC GPIO output, and one RS-232 pass-through. It also supports bi-directional 24V POC. This extender is ideal for long-distance signal transmission between a PC and USB devices.

EX-FS-100 - VAVE USB3.0 Extender 100m



The USB 3.0 Extender extends USB signals up to 100m (328ft) using a single CAT6a cable. The transmitter includes one USB 3.0 Type B input, one FSYSNC GPIO input, and one RS-232 pass-through. The receiver provides four USB 3.0 Type A outputs, one FSYSNC GPIO output, and one RS-232 pass-through. It also supports bi-directional 24V POC. This extender is ideal for long-distance signal transmission between a PC and USB devices.

Feature :



  • Extension of USB 3.0 up to 100m/328ft over CAT6a cable
  • USB 3.0 connectivity with data transfer rate up to 5Gbps
  • Backwards compatible with USB 2.0 and 1.1
  • Hardware acceleration for isochronous and bulk transfer
  • USB-A port 1 and 2 support 5V/1.5A, port 3 and 4 support 5V/1A on the Receiver
  • Support RS-232 pass-through and FSYNC GPIO pass-through (for industry camera use)
  • Support bi-directional 24V POC
  • Simple plug and play, no driver and setting installation required

Specifications

Technical
USB Protocol USB -.0
Transmission Rate Up to 5Gbps
Network Bandwidth 10G
Transmission Distance 100m/328ft over CAT6a (F/FTP) cable
ESD Protection IEC 61000-4-2: ±8kV (Air-gap discharge), ±4kV (Contact discharge)
Connections
Transmitter
Input 1 × USB HOST [USB-B, 9pin Female]
Output 1 × HDBT OUT [RJ45, Female]
Control 1 × RS-232 [3pin-3.5mm Phoenix Connector]
1 × FSYNC [1pin-3.5mm Phoenix Connector]
1 × SERVICE [USB-C, Update Port]
Receiver
Input 1 × HDBT IN [RJ45, Female]
Output 4 × USB Devices [USB-A, 9pin Female]
Control 1 × RS-232 [3pin-3.5mm Phoenix Connector]
1 × FSYNC [1pin-3.5mm Phoenix Connector]
1 × SERVICE [USB-C, Update Port]
Mechanical
Housing Metal Enclosure
Color Black
Dimensions Transmitter / Receiver: 85mm [W] × 100mm [D] × 25.5mm [H]
Weight Transmitter: 253g, Receiver: 260g
Power Supply Input: AC 100~240V 50/60Hz
Output: DC 24V/2A
Power Consumption PoC Power Supply: 40W (Max)
Operation Temperature 0°C ~ 40°C / 32°F ~ 104°F
Storage temperature -20°C ~ 60°C / -4°F ~ 140°F
Relative Humidity 20~90% RH (non-condensing)
