AVIP-DE-DAN - VAVE Dante 2CH Analog Audio Decoder with POE

AVIP-DE-DAN - VAVE Dante 2CH Analog Audio Decoder with POE
AVIP-DE-DAN - VAVE Dante 2CH Analog Audio Decoder with POEAVIP-DE-DAN - VAVE Dante 2CH Analog Audio Decoder with POEAVIP-DE-DAN - VAVE Dante 2CH Analog Audio Decoder with POEAVIP-DE-DAN - VAVE Dante 2CH Analog Audio Decoder with POE
รหัสสินค้า SKU-02384
หมวดหมู่ VAVE
ราคา 0.00 บาท
VAT7% สอบถามเพิ่ม
สถานะสินค้า Pre-Order
ลงสินค้า 18 ม.ค. 2568
อัพเดทล่าสุด 18 ม.ค. 2568
คงเหลือ ไม่จำกัด
จำนวน
ชิ้น
หยิบลงตะกร้า
หนังสือรับรองบริษัท
บุ๊คแบ๊งค์
คุ้มครองโดย LnwPay
Tags : HDMI, 4K60, CAP, encoder, USB Audio, Audio Processor

รายละเอียดสินค้า

AVIP-DE-DAN - VAVE Dante 2CH Analog Audio Decoder with POE This Dante 2CH Analog Audio Decoder is an audio receiver that utilizes the Dante Ultimo solution. It offers both balanced and unbalanced audio output, along with a 3-level gain adjustment feature. The device receives audio signals from the transmitting end over a Dante network, decodes the signals, and outputs them as analog audio. Additionally, it supports Power over Ethernet (POE) functionality.

AVIP-DE-DAN - VAVE Dante 2CH Analog Audio Decoder with POE



This Dante 2CH Analog Audio Decoder is an audio receiver that utilizes the Dante Ultimo solution. It offers both balanced and unbalanced audio output, along with a 3-level gain adjustment feature. The device receives audio signals from the transmitting end over a Dante network, decodes the signals, and outputs them as analog audio. Additionally, it supports Power over Ethernet (POE) functionality.

Feature :

  • Analog audio output supports balanced/unbalanced audio output (unbalanced access to “+” and “GND”)
  • Audio sampling rate supports 44.1kHz, 48kHz and 96kHz (24bit)
  • Dante solution supports AES67 RTP audio transmission
  • Audio output supports 3-level gain adjustment：+18dBu, 0dBu (default) and -10dBV
  • Support DC 12V power supply and POE function (IEEE802.3af Class 0)

Specifications

Technical
Video Network Bandwidth 100M
Audio Formats PCM 2.0 44.1kHz/48kHz/96kHz up to 24bit
Transmission Distance 100m (CAT6/6A)
Control Method Dante Controller
Connection
Input 1x DANTE [RJ45 connector, POE]
1x PWR [2-pin phoenix, 3.81mm]
Output 1x AUD [6-pin phoenix, 3.81mm]
Mechanical
Housing Metal Enclosure
Color Black
Dimensions 120mm[W] x 47mm[D] x 26mm[H]
Weight 186g
Power Supply DC input: 12V
POE input: IEEE802.3af Class 0
Power Consumption 1.32W
Operation Temperature 32 – 104oF / 0 – 40oC
Storage temperature -4 – 140oF / -20 – 60oC
Relative Humidity 20 – 90% RH (no condensation)
