Mic Sensitivity
-37 dBV ± 2 dBV@1 kHz, 94dB SPL
Wireless Modulation Mode
GFSK 2 Mbps
Wireless Transmission
2.4 GHz Adaptive Frequency Hopping (AFH)
Transmission Range
TX: 1,115ft (340m) for LOS / 197ft (60m) for NLOS
OWS Monitor Earphone: 328ft (100m) for LOS / 197ft (60m) for NLOS
OWS Monitor Earphone: 328ft (100m) for LOS / 197ft (60m) for NLOS
Mic Polar Pattern
Omnidirectional
Frequency Response
20 Hz – 20 kHz
Signal-to-Noise Ratio
≥ 72dB
Max Sound Pressure Level
128dB SPL
Sample Rate and Bit Depth
48 kHz / 32-bit Float & 48 kHz / 24-bit
Battery Voltage
TX: 3.87V
Camera RX: 3.87V
Charging Case: 3.8V
OWS Monitor Earphone: 3.7V
Earphone Charging Case: 3.7V
Camera RX: 3.87V
Charging Case: 3.8V
OWS Monitor Earphone: 3.7V
Earphone Charging Case: 3.7V
Battery Capacity
TX: 167 mAh
Camera RX: 300 mAh
Charging Case: 2000 mAh
OWS Monitor Earphone: 90 mAh
Earphone Charging Case: 500 mAh
Camera RX: 300 mAh
Charging Case: 2000 mAh
OWS Monitor Earphone: 90 mAh
Earphone Charging Case: 500 mAh
Operating Time
TX: Approx. 11 hours
Camera RX: Approx. 12 hours
OWS Monitor Earphone: Approx. 18 hours
Camera RX: Approx. 12 hours
OWS Monitor Earphone: Approx. 18 hours
Charging Cycle
Charging Case: > 2.5 times charging for 2 TX and Camera RX at the same time
Earphone Charging Case: > 1.8 times charging for 2 OWS Monitor Earphone at the same time
Earphone Charging Case: > 1.8 times charging for 2 OWS Monitor Earphone at the same time
Charging Time
TX: Approx. 1.5 hours
Camera RX: Approx. 1.5 hours
Charging Case: Approx. 2 hours
OWS Monitor Earphone: Approx. 1.6 hours
Camera RX: Approx. 1.5 hours
Charging Case: Approx. 2 hours
OWS Monitor Earphone: Approx. 1.6 hours
Charging Temperature
0 ~ 45° C
Operating Temperature
-10 ~ 55° C
Dimensions
TX: 23.4*10.2*45.1mm (0.92″ × 0.40″ × 1.78″)
Camera RX: 54.2*22.3*29.5mm (2.13″ × 0.88″ × 1.16″)
USB-C RX: 40.7*9.1*27mm (1.60″ × 0.36″ × 1.06″)
Camera RX: 54.2*22.3*29.5mm (2.13″ × 0.88″ × 1.16″)
USB-C RX: 40.7*9.1*27mm (1.60″ × 0.36″ × 1.06″)
Weight
TX: Approx. 14g (0.51oz)
Camera RX: Approx. 24g (0.85oz)
Charging Case: Approx. 136g (4.8oz)
USB-C RX: Approx. 5.9g (0.21oz)
Camera RX: Approx. 24g (0.85oz)
Charging Case: Approx. 136g (4.8oz)
USB-C RX: Approx. 5.9g (0.21oz)
Note:
1.
The hot shoe adapter is compatible with select Sony camera models and must be purchased separately. Compatible camera models:
ZV-E1/ZV-E10/ILCE-9M3/ILCE-7SM3/ILCE-7RM5/ILCE-7RM4/ILCE-7CR/ILCE-7CM2/ILCE-7C/ILCE-7M4/ILCE-6700/ILCE-FX3
ZV-E1/ZV-E10/ILCE-9M3/ILCE-7SM3/ILCE-7RM5/ILCE-7RM4/ILCE-7CR/ILCE-7CM2/ILCE-7C/ILCE-7M4/ILCE-6700/ILCE-FX3
2.
Internal recording offers flexible recording options to freely switch between 24-bit and 32-bit float to suit your needs.
3.
Wireless monitoring is unavailable in 4 Transmitters & 1 Receiver mode.
4.
Choose the Combo 4-Person Version or purchase extra transmitters to expand your configuration to fit a variety of shooting scenarios.
5.
All working time mentioned refers to the transmitter.
6.
The receiver's USB-C port is MFi certified.
7.
In Combo 4-Person Version, the two additional transmitters that do not fit in the charging case are stored separately in the carrying bag.
8.
The transmitter's wearable design includes a magnetic disk, which might interfere with implantable electronic devices. To avoid potential issues, please keep the transmitter at a safe distance from these devices.
