AJA HELO H.264 Streamer & Recorder

AJA HELO H.264 Streamer & Recorder
HELO is AJA's new H.264 streaming and recording stand-alone appliance. HELO brings both SDI and HDMI I/O into a single appliance with the ability to simultaneously stream out to your Content Delivery Network (CDN) as well as encode and record beautiful H.264 files to either SD cards, USB storage or network based storage simultaneously. Portable and Packed to go HELO's small and robust form factor is essential for your busy schedule. Live events, webcasts, production and post locations vary and you need a device that can take the heat. HELO is designed to travel well, fit wherever needed and continuously deliver; all with full size connectivity. HELO offers both HD-SDI and HDMI source inputs in a single device with the ability to encode up to 1080p 60 in beautiful and efficient H.264. Stream out to your Content Delivery Network (CDN) and record to SD cards, USB storage or network based shares simultaneously. CONNECT Your projects vary, you need flexible connectivity HELO delivers with 3G-SDI and HDMI video inputs and outputs. 24-bit audio at 48 kHz embedded in the SDI or HDMI signal ensures you never lose sync, plus Line Level, Unbalanced stereo 3.5mm TRS connectors have you covered. ENCODE Your goal is efficiency with beautiful results HELO encodes to H.264/MPEG-4 ensuring bandwidth efficiencies with widely compatible files. From tablets to Smartphones, Desktops to Smart TVs, no

Video Formats	2K: 2048 x 1080p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 HD: 1080p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 HD: 1080i 25, 29.97, 30 HD: 720p 50, 59.94, 60 SD: 525i, 625i (2K inputs are center cut to 1080p and are only supported on SDI input)
Video Codec Support	H.264/MPEG-4 Encoder
Video Parameters	100 KB/s to 20 MB/s (TBD) streamed output 100 KB/s to 20 MB/s (TBD) recorded output Up to 1080p60 Supports Baseline, Main and High 2.0, 3.0, 3.1, 4.0 and 4.1 level support
Video Input Digital	1 x 3G-SDI, SMPTE-259/292/296/424, 10-bit Single Link 4:2:2, 4:4:4 (1 x BNC) 1 x HDMI Standard Type A connector HDMI v1.4a, RGB or YCbCr
Video Output Digital	1 x 3G-SDI, SMPTE-292/296/424, 10-bit Single Link 4:2:2 or 4:4:4 (1 x BNC) 1 x HDMI Standard Type A connector HDMI v1.4a, RGB or YCbCr
Audio Encoding	32 KB/s to 256 KB/s 32, 44.1 and 48 kHz 2-channel stereo MPEG-4 AAC-LC
Audio Input Digital	2-channel, 24-bit SDI embedded audio, 48 kHz sample rate, synchronous 2-channel, 24-bit HDMI embedded audio, 48 kHz sample rate, synchronous
Audio Input Analog	2-channel, Analog (Line Level, Unbalanced stereo 1 x 3.5 mm TRS connector)
Audio Output Digital	2-channel, 24-bit SDI embedded audio, 48 kHz sample rate, synchronous 2-channel, 24-bit HDMI embedded audio, 48 kHz sample rate, synchronous
Audio Output Analog	2-channel, Analog (Line Level, Unbalanced stereo 1 x 3.5 mm TRS connector)
Protocols	RTMP, RTSP/RTP, Unicast and Multi Unicast (3 to 10 Clients)
Storage	1 x USB 2.0 slot, (Can be NTFS 3.1 or FAT32) 1 x SD Card slot, SD and SDHC cards (NTFS 3.1) Mounted Network Share
User Interface	Stream Button Record Button Web UI Simple Web Configuration via AJA eMini-Setup (OS X and PC)
Power	100 to 240 V, 50/60 Hz Universal Input, +5-20 VDC 13 W Maximum
Environment	Operating Temperature: 32 to 104°F (0 to 40°C) Operating Relative Humidity: 10 to 90% non-condensing Operating Altitude: <10,000' (3,000 m) Safe Storage Temperature (Power OFF): -40 to 140°F (-40 to 60°C)
Dimensions (W x D x H)	7.0 x 4.7 x 1.0" (18 x 14 x 26 cm)
Weight	0.8 lb (0.4 kg)
